electric lift hoist
Product Introduction
China coal special produce vehicle-mounted electric crane ,with DC12V Vehicle power as power .Specially suitable in outdoor on power place , it is widely used ,mainly used for light-weight wagon ,Vans, loading dock ,platform .Outstanding feature ,compact structure , single size , lightest weight take up minimal room , HP1000 matched with 3000lbswinch ,is the best ideal option for lifting little object.
500kgs Electric Truck Hoist Winch / Electric Hoist/ electric winch/ DC12V hoist
Electric truck hoist winch description
Electric Truck Hoist Winch is an economical alternative to costly truck mounted hydraulic cranes. It is suitable for mounting on utilities, light trucks, trailers or pontoons, etc.
1000lbselectric TRUCK hoist is one of our professional products, with 12 volt DC as the power. It is widely used in pick -up trucks, caravan cars, loading docks, platforms etc. With outstanding featuressuch as structurally compact, small sized, light weighted, and minimal space required, ZM1000 is a good helper for lifting goods equal to or less than660lbsin weight.
Main Parameter
MODEL:
|
HP1000
|
Single line Lifting Capacity(maximum)
|
500kg
|
Double-line Lifting Capacity(maximum)
|
800kg
|
Lifting Height Max.Std.(base to hook)
|
1940mm
|
Reach Max.(from center of rotation)
|
1490mm (see Figure 3)
|
Rotation (continuous) with Brake
|
360° Manual
|
Lifting Cable
|
4.8mm x4.5m–1pc(for single-line lifting)
4.8mm x5.5m—1pc(for double-line lifting)
|
Line speed with No Load
|
3.6m/min single line
|
Power Requirements
|
12V DC 125 amps
|
Switch Cable
|
4.2m
|
Mounting Base
|
250x250x18mms
|
Mounting Bolt Hole Pattern
|
170x170mms
|
Finish
|
Powder Coated
|
Net Weight of Crane (LBS)
|
58.5KGS
|
